Lieu d'origine: | La Chine |
Nom de marque: | FESTO |
Numéro de modèle: | DGC-12-600 - G-P-A |
Quantité de commande min: | 1pc |
---|---|
Prix: | EXW USD300-400 |
Détails d'emballage: | Sachet en plastique, carton |
Délai de livraison: | jours 7-10working |
Conditions de paiement: | T/T, Western Union, Paypal |
Capacité d'approvisionnement: | 20 PCs par mois |
Type: | DGC-12-600 - G-P-A | Numéro de la pièce: | 530907 |
---|---|---|---|
Marque: | FESTO | Diamètre de piston: | 12 millimètres |
Position de montage: | Facultatif | Joints matériels: | POM TPE-U (UNITÉ CENTRALE) |
Surligner: | Linear Drive Double Acting Pneumatic Cylinder,530907 Pneumatic Air Cylinders,12mm Piston Pneumatic Air Cylinders |
About product
Basic design, plain or ball bearing guide, guide axis without actuator
All settings accessible from one side
Available with variable end stops and intermediate position module
Compact – installation length relative to stroke
Loads and devices can be directly mounted on the slide
Long strokes with no restrictions
Virtually no leakage
Technical Data
Piston diameter | 12 mm |
Mounting position | optional |
Guide | Basic guide Recirculating ball bearing guide |
Position detection | Via proximity switch |
Operating pressure | 0.25 MPa ... 0.8 MPa |
Operating pressure | 2.5 bar ... 8 bar |
Mode of operation | Double-acting |
Corrosion resistance class CRC | 1 - Low corrosion stress 2 - Moderate corrosion stress |
LABS (PWIS) conformity | VDMA24364-B1/B2-L |
Type of mounting | With accessories |
Note on materials | RoHS-compliant |
Material cover | Wrought aluminium alloy |
Material seals | POM TPE-U(PU) |
Package picture
A wide range of products with excellent prices. Please hurry to me!
